Telecommunications Single Mode Fibre Patch Leads 50/125 ST To LC Fiber Jumper

Product Categories

Cixi Jinwo Communications Equipment Co., Ltd.

Contact Now

Telecommunications Single Mode Fibre Patch Leads 50/125 ST To LC Fiber Jumper

Name: Telecommunications Single Mode Fibre Patch Leads 50125 ST To LC Fiber Jumper
Brand: JINWO
Price: 1 USD

Wholesale Telecommunications Single Mode Fibre Patch Leads 50/125 ST To LC Fiber Jumper from china suppliers

Brand Name : JINWO

Model Number : JW-PC-009

Certification : ISO9001

Place of Origin : NINGBO

MOQ : 500pcs

Price : Negotiable

Payment Terms : T/T, Western Union

Supply Ability : 10000pcs each moth

Delivery Time : 8work days

Packaging Details : Normal

Type : DX/SX

Length : Customized

Color : Customized

Application : FTTH FTTB FTTX Network

Cable diameter : 0.9mm

Cord type : Simplex ,Duplex

Contact Now

Fiber Optic Patch Cord SC - SC Connector Singlemode SM Simplex SX Can Customize

Compliant with international standards such as ANSI, Bellcore, TIA/EIA, IEC, also accord with the industrial standards of Telecom in China Realize the active link of optic fiber transmission

Low insertion loss and high return loss

Excellent repeatability and interchangeability

FEATURES

1. Low insertion loss and back reflection loss
2. Ferrule end surface pre-domed
3. Excellent mechanical endurance
4. Good in repeatability
5. Good in exchange
6. Green Production, CE, RoHS Standard

APPLICATION

1. Telecommunications
2. CATV, LAN, MAN, WAN, Test &Measurement
3. Military industry
4. Medical

CABLE PARAMETERS

Fiber brand: YOFC, FIBERHOME

Cord type:Simplex ,Duplex

Cable jacket:PVC, OFNR, LSZH, OFNP

Cable diameter:0.9mm,2.0mm,3.0mm

Length:3m or customized

Telecommunications Single Mode Fibre Patch Leads 50/125 ST To LC Fiber Jumper

SPECIFICATION

Model	Single Mode (G652D,G657A1,G657A2,G657B3)		Multi Mode (OM1,OM2,OM3,OM4)
Polish	UPC	A PC	PC
Insertion Loss	≤0.30dB	≤0.20dB	≤0.20dB
Return Loss	≥50dB	≥60dB	≥45dB
Test Wavelength	1310/1550nm		850/1310nm
Durability(500 Matings)	≤0.2dB
Operating Temperature	-45℃~+80℃
